Description
10/100/1000Base-T PoE RJ45 Gigabit Ethernet to 1000Base-FX Open SFP Fiber Media Converter (Distance depending on SFP module)
The PMC-GSA11-L is a gigabit PoE fiber media converter designed to convert 10/100/1000BASE-T copper to 1000BASE-X fiber optic while providing Power over Ethernet cable (PoE) to IEEE 802.3af PoE compliant devices such as IP surveillance cameras, VoIP phones, wireless access points, and other network devices. This SFP PoE media converter acts as Power Sourcing Equipment (PSE) device to provide power to Powered Devices (PD) that comply with the IEEE 802.3af standard. The auto-sensing function can supply power to PD devices and stop supplying power once the PoE device disconnected.
The PoE media converter provides a perfect PoE solution to deliver data and power network devices saves you the cost and effort of buying, connecting, and installing extra power supplies and electrical cabling for each device.
This SFP PoE media converter provides an open Gigabit SFP slot, allowing you to choose the MSA-compliant pluggable optics that best meet your fiber connection needs. This SFP fiber media converter lets you choose a wide range of SFP transceivers that suit your singlemode or multimode cabling systems, such as 1G SFP transceiver, BiDi SFP transceiver, and CWDM SFP transceiver, and supports transmission distances up to 160 kilometers (99.4miles) depends on different SFP modules. The Gigabit SFP media converter offers a flexible and cost-effective way to extend the distance of an existing copper network, the life of non-fiber-based equipment, or the distance between two devices, allowing you to maximize the usage and performance of legacy equipment.
Features
• IEEE 802.3af power on the POE port
• Auto-negotiation function allows UTP ports to auto select 10/100/1000M and Full Duplex or Half Duplex
• The UTP port supports the connection of MDI/MDI-X auto crossover
• Gigabit Open SFP slot to customize the network extension distance to your requirements with any MSA-compliant transceiver
• Supporting flow control for Full-duplex Mode and backpressure for Half-duplex Mode
• Easy-to-view LED indicators to provide status to monitor network activity easily
• Compacts size for easy installation and working with Optcore 14-Slot Media Converter Rackmount Chassis(MC-RACK-14)
• ROHS compliant and Lead-Free
Specification
| Product Series | PoE Media Converter | Standards and Protocols | IEEE 802.3, IEEE 802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3af |
| Ports | 1 x 10/100/1000BASE-T RJ45 port 1 x 1000BASE-X Open SFP port |
Network Media | 10/100/1000Base-T: Cat 5 UTP (max 100m) 1000Base-X: Multimode or Singlemode Fiber (maximum 160km, depends on the SFP transceiver) |
| Flow control | Full Duplex: IEEE802.3x Half Duplex: back pressure |
LED indicator | POWER (power) FX LINK (fiber link action) TP LINK1000 (twisted pair connection 1000M) TP LINK100 (twisted pair connection 100M) TP ACT (twisted-pair packet forwarding action) FDX (Ethernet interface mode indicator, ON Full duplex/OFF: Half-duplex) |
| Buffer space | 256 KB | MAC address | 4K |
| Wavelength | Depends on SFPs | Fiber Type | Multimode or Singlemode Fiber |
| Transmitter Power | Depends on SFPs | Receiver Sensitivity | Depends on SFPs |
| Power Supply | External Power Adapter Input: AC 100~240V 50/60Hz Output: DC 52V 0.7A |
Power Over Ethernet (PSE) | 15.4W |
| Dimensions (WxDxH) | 26×70×93mm | Gross Weight | 0.6 kg |
| Environment | Operating: 0°C to 50°C, 10~90% RH Storage: -40°C to 70°C, 5~90% RH |
Compliance | FDA IEC/EN 60825-1 ROHS, CE |
